Deploying module embedded in the application

The adapter is deployed embedded in the application and specific to it. The adapter cannot be shared between multiple applications.

The following steps are a necessary prerequisite to configure and deploy the module.

To create an application with the embedded adapter, use the external service wizard.


Procedure

  1. In the Service Configuration Properties window, from the Deploy connector project property list, select With module for use by single application.

  2. Create the module as described in the Business process management samples for WebSphere Adapters.

  3. In the Dependencies option for the module, after the module is created, ensure that the Deploy with module option is selected for the adapter.

  4. If the server is not running, right-click your server in the Servers view and select Start.

  5. When the server status changes to Started, right-click the server and select Administration > Run administrative console.

  6. From the Deployment Manager Admin Console, click Install applications to deploy the application.

  7. On the Step 2: Map modules to servers window, select the module and click Next. For the embedded adapter option, the adapter is deployed as part of the application.

  8. In the Enterprise Applications view, select the new application <adapter_name>EmbeddedModuleApp. The new application is displayed after the application is deployed at the dmgr level.

  9. Select the node and click Installed applications to view the deployed application on each individual node.


Results

The resource adapter is embedded and deployed as part of the application.
