Example 2: Configure basic authentication, identity assertion, and client certificates

This example is the same as example 1, except for the interaction from client C2 to server S2. Therefore, the configuration of example 1 still is valid, but we have to modify server S2 slightly and add a configuration for client C2. The configuration is not modified for C1 or S1.

1. Configure client C2 for transport layer authentication (SSL client certificates).

   1. Point the client to the sas.client.props file.

      (dist) Use the com.ibm.CORBA.ConfigURL=file:/C:/was/properties/sas.client.props property. All further configuration involves setting properties within this file.

      (iseries) Use the com.ibm.CORBA.ConfigURL=file:/ profile_root /properties/sas.client.props property. The profile_root variable is the specific profile that you are working with. All further configuration involves setting properties within this file.

   2. Enable SSL.

      In this case, SSL is supported but not required:

      com.ibm.CSI.performTransportAssocSSLTLSSupported=true,
      com.ibm.CSI.performTransportAssocSSLTLSRequired=false

   3. Disable client authentication at the message layer.

      com.ibm.CSI.performClientAuthenticationRequired=false,
      com.ibm.CSI.performClientAuthenticationSupported=false

   4. Enable client authentication at the transport layer where it is supported, but not required.

      com.ibm.CSI.performTLClientAuthenticationRequired=false,
      com.ibm.CSI.performTLClientAuthenticationSupported=true

2. Configure the server, S2.

   In the console, server S2 is configured for incoming requests to SSL client authentication and identity assertion. Configuration for outgoing requests is not relevant for this example.

   We can mix and match these configuration options. However, a precedence exists as to which authentication features become the identity in the received credential:

   1. Identity assertion

   2. Message-layer client authentication (basic authentication or token)

   3. Transport-layer client authentication (SSL certificates)

   1. Enable identity assertion.

   2. Disable user ID and password authentication.

   3. Enable SSL.

   4. Enable SSL client authentication.
