Concepts: JavaBean Topics Introduction JavaBean Properties Indexed Properties Bound Properties Constrained Properties Events and Notification Introspection Persistence Customization BeanContext JavaBeans™ Activation Framework More Information   Introduction JavaBeans define a simple and powerful component model for Java. The goal of JavaBeans is to provide for self-contained and reusable units that can be manipulated programmatically by developers or visually in builder tools. JavaBeans can be GUI controls or they may be lacking visual representation. GUI controls in Java are typically JavaBeans in order to be manipulated by the builder tools. In J2EE, simple JavaBeans are commonly used from JSPs, where they provide for separation of presentation in HTML and the Java code, which is contained in the JavaBeans. A JavaBean is a Java class with three distinctive features: Properties, Events, and Methods.   JavaBean Properties Properties of a JavaBean can be access by other components. Typically, a property is a private value accessed through setter and getter methods, but it can be a computed value as well. Updates of properties can have various side effects. Accessors are methods for accessing properties. Accessors can be getters and setters, and they follow naming conventions: void setPropertyName(PropertyType value); // setter PropertyType getPropertyName() // getter For a boolean property, a getter can be: boolean isPropertyName() // getter for a boolean property Example: Customer Bean The following is an example of a simple JavaBean (Customer) with two simple properties: name and email. Notice how the properties are defined through the pairs of set/get methods. public class Customer { private String name; private String email; public String getName() { return name; } public void setName(String aName) { name = aName; } public String getEmail() { return email; } public void setEmail(String aEmail) { email = aEmail; } } Such simple JavaBeans are often used in JSPs, where they enable transport of values from forms on the web pages. Indexed Properties Besides simple properties, which have a single value, a property can be a set of values contained in an array. Indexed properties can return a value at the specified index, or the whole array of values. Indexed properties have the following signatures: void setPropertyName(int index, PropertyType value); // indexed setter PropertyType getter(int index); // indexed getter void setPropertyName(PropertyType values[]); // array setter PropertyType[]getPropertyName(); // array getter Bound Properties The bound property mechanism provides for notification service when the property changes. Interested objects that wish to be notified of the change register themselves in advance, and when the property change occurs, the registered objects are sent the notification. Typically, this notification is done through an event fired by the component with the bound property after the property has been set. A JavaBean with a bound property exposes methods for registration and deregistration of interested objects, called listeners. The developers can define their own notification mechanism, but the Java libraries provide a number of commonly used support classes in the java.beans package. Constrained Properties Constrained properties are similar to bound properties, but the notification happens before the property is actually set. That enables interested parties to disallow the change of the property by throwing a PropertyVetoException.   Events and Notification Events are the feature of JavaBeans which enables independently developed components to communicate with each other by propagating information about the state change. In this model, some components fire events, which are handled by other components, in the role of the event listeners. To support this communication model, JavaBeans component model provides: properties that can fire events (bound and constrained properties), registration methods, so that listeners can register themselves, events, which carry information about the change, and listeners, which can react on the delivered event. The following class diagram illustrates these concepts for a JavaBean called EventSource with a simple int property. During configuration, concrete listeners register with the JavaBean. At some point later, some other object calls the setProperty method, which will start the notification process by creating the event object. The EventSource JavaBean will invoke the propertyChange method on all registered listeners. Event listeners will receive the event, read the values from it and react on the event. The following sequence diagram illustrates the order of invocations: Notification of listeners is synchronous with respect to the JavaBean instance, which is the source of the event, but the event listener can do the processing of events in another thread.   Introspection Introspection is a run-time mechanism that enables detection of properties, events and methods of a JavaBean. Introspection is used by development tools and by programs that do not use hard-coded dependencies on other components. Introspection is achieved through reflection and a set of conventions for naming of methods and interfaces. Additional features of introspection are supported by the BeanInfo class. JavaBeans naming conventions used for introspection are sometimes called "design patterns", but they should not be confused with the notion of design pattern in object-oriented design.   Persistence A JavaBean can be persisted through a serialization mechanism. The serialization can be automatic or custom, depending if the JavaBean implements Serializable or Externalizable interfaces. JDK 1.4 introduces XMLEncoder and XMLDecoder classes that provide for storing of JavaBeans instances in the XML format.   Customization The appearance and behavior of a JavaBean can be customized at design time. This is particularly important for visual JavaBeans that are used in graphical user interfaces. The customization is done through a property editor or by using customizers. Customizers provide a custom user interface for configuring a JavaBean instance at design time.   BeanContext BeanContext defines a logical containment hierarchy that enables JavaBeans to interrogate their environment for capabilities and services. BeanContext mechanisms provide support for logical containment hierarchy of JavaBeans and lookup of services offered by JavaBeans in the hierarchy.   JavaBeans™ Activation Framework The Java Activation Framework is a standard Java extension which enables determination of the type of a piece of data, encapsulation of it, discovery of its available operations and instantiation of a software component that corresponds to the desired operation on the piece of data.   More Information For more information on JavaBeans, see the JavaBeans API Specification, Version 1.01 at http://java.sun.com/. Follow the links to Docs & Training > Java 2 Platform, Standard Edition > Java 2 SDK, SE v1.3 documentation > JavaBeans > JavaBeans Specification. This content developed or partially developed by Inferdata Corporation. © Copyright IBM Corp. 1987, 2004. All Rights Reserved.
