Get started with wsadmin scripting
The WAS wsadmin tool provides the ability to run scripts. The wsadmin tool supports a full range of product administrative activities.
The following figure illustrates the major components involved in a wsadmin scripting solution:
Figure 1: A WAS scripting solution
The wsadmin tool supports two scripting languages: Jacl and Jython. Five objects are available when you use scripts:
- AdminControl: Use to run operational commands.
- AdminConfig: Use to run configurational commands to create or modify WAS configurational elements.
- AdminApp: Use to administer applications.
- AdminTask: Use to run administrative commands.
- Help: Use to obtain general help.
The scripts use these objects to communicate with MBeans that run in WAS processes. MBeans are Java objects that represent JMX resources. JMX is an optional package addition to Java 2 Platform Standard Edition (J2SE). JMX is a technology that provides a simple and standard way to manage Java objects.
Some wsadmin scripts, including the AdminApp install, AdminApp update, and some AdminTask commands, require that the user ID under which the server is running must have read permission to the files that are created by the user that is running wsadmin scripting. For example, if the application server is running under user1, but you are running wsadmin scripting under user2, you might encounter exceptions involving a temporary directory. When user2 runs wsadmin scripting to deploy an application, a temporary directory for the enterprise application archive (EAR) file is created. However, when the application server attempts to read and unzip the EAR file as user1, the process fails. It is not recommended that you set the umask value of the user that is running wsadmin scripting to 022 or 023 to work around this issue. This approach makes all of the files that are created by the user readable by other users.
To resolve this issue, consider the following approaches based on your administrative policies:
- Run wsadmin scripting with the same user ID as the user that runs the dmgr or application server. A root user can switch the user ID to complete these actions.
- Set the group ID of the user that is running the dmgr or application server to be the same group ID as the user that is running wsadmin scripting. Also, set the umask value of the user that is running the wsadmin scripting to be at least a umask 027 value so that files that are created by the wsadmin scripting can be read by members of the group.
- Run wsadmin scripting from a different machine. This approach forces files to be transferred and bypasses the file copy permission issue.
To perform a task using scripting, first perform the following steps:
Procedure
- Choose a scripting language. The wsadmin tool only supports Jacl and Jython scripting languages. Jacl is the language specified by default. To use Jython, use the -lang option or specify it in the wsadmin.properties file.
- Start the wsadmin scripting client interactively, as an individual command, in a script, or in a profile.
What to do next
Before you perform any task using scripting, make sure that you are familiar with the following concepts:
- JMX
- WAS configuration model
- wsadmin tool
- Jacl syntax or Jython syntax
- Scripting objects
Optionally, you can customize your scripting environment. See Administrative properties for using wsadmin.sh.
After you become familiar with the scripting concepts, choose a scripting language, and start the scripting client, you are ready to perform tasks using scripting.
