Installing the EAR file

Installing the EAR file is the last step of the deployment process. When install the EAR file on the server and run it, the adapter, which is embedded as part of the EAR file, runs as part of the installed application.

You must have exported your module as an EAR file before you can install it on IBM BPM or WebSphere Enterprise Service Bus.

To install the EAR file, perform the following procedure. For more information about clustering adapter module applications, see the http://www.ibm.com/software/webservers/appserv/was/library/.


Procedure

  1. If the server is not running, right-click your server in the Servers view and select Start.

  2. When the server status changes to Started, right-click the server and select Administration > Run administrative console.

  3. Log on to the administrative console.

  4. Click Applications > New Application > New Enterprise Application.

    Figure 1. Preparing for the application installation window

  5. Click Browse to locate your EAR file and click Next. The EAR file name is the name of the module followed by "App."

  6. If you are deploying to a clustered environment.

    1. On the Step 2: Map modules to servers window, select the module and click Next.

    2. Select the name of the server cluster.

    3. Click Apply.

  7. Click Next. In the Summary page, verify the settings and click Finish.

  8. If you are using an authentication alias:

    1. Expand Security and select Business Integration Security.

    2. Select the authentication alias that you want to configure. You must have administrator or operator rights to change the authentication alias configurations.

    3. If it is not already specified, type the User name.

    4. If it is not already specified, type the Password.

    5. If it is not already specified, type the password again in the Confirm Password field.

    6. Click OK.


Results

The project is now deployed and the Enterprise Applications window is displayed.


What to do next

If you want to set or reset any properties or you would like to cluster adapter project applications, make those changes using the Process Administrative Console before configuring troubleshooting tools.
